Introducing the All-New K4 Notched Disc Chain: Power and Versatility for Your Fields

Why Choose the K4 Notched Disc Chain?

Aggressive Cutting Action

The K4 Notched Disc Chain is engineered for superior cutting and mixing of crop residue.

Designed for Performance

Several years ago, we launched the smooth K4 disc to provide more effective weed control during seedbed preparation. The new K4 Notched Disc has been designed to provide a more aggressive action sizing residue in the fall.

Versatile Performance

Whether you’re working in loamy, wet soils or tougher conditions, the K4 Notched Disc Chain adapts to deliver optimal performance.

Customizable Cutting Action with Two Blade Options

The choice is yours with the K4 Notched Disc Chain featuring interchangeable smooth and notched blades for ultimate versatility in your tillage.

Choose between sharp smooth-edged blades for a clean, precise cut or sharp notched blades for aggressive residue management, giving you the flexibility to adapt to any field condition.

Additionally, you can easily add weights to enhance penetration and cutting efficiency, ensuring optimal performance even in the toughest soil conditions.

Extra weights

Notched

Smooth

STRENGTH MEETS SIMPLICITY

Every part of the K4 has been designed with simplicity in mind. Closer disc spacing creates an overlap that allows for full soil coverage at the shallow working depth. The bolt-on design allows links to be added or removed from the chain without the need for disassembly. All of these elements combine to make a Disc Chain that’s strong, simple and endlessly reliable.

K4-N SPECIFICATIONS

UNIT WEIGHT

11kg

CHAIN WEIGHT

68kg/m

DIAMETER

330mm

DISC CONCAVITY

25°

SPACING

160mm

ADJUST WITH EXTRA WEIGHTS

By adding bolt-on weights directly to the chain, you can improve penetration and cutting power without compromising the chain’s simplicity. It’s the same strong, reliable K4 design, with the added flexibility to take on harder, more compact soils with ease.

WEIGHTED K4-N SPECIFICATIONS
